The ArrayList class is a resizable-array implementation of the List interface. Unlike a normal array, an ArrayList can grow in size as you add more items to it. The example below illustrate some of the useful methods of the ArrayList class using an ArrayList of String objects.

import java.util.ArrayList;

public class ArrayListDemo {

    public static void main(String args[]) {
        ArrayList<String> items = new ArrayList<>();

        System.out.println("Before adding any items:" + items);

        items.add("Apple");
        items.add("Box");
        items.add("Cup");
        items.add("Dart");
        print("After adding four items: " + items);

        items.remove("Box"); // remove item "Box"
        print("After removing Box: " + items);

        items.add(1, "Banana"); // add "Banana" at index 1
        print("After adding Banana: " + items);

        items.add("Egg"); // add "Egg", will be added to the end
        items.add("Cup"); // add another "Cup"
        print("After adding Egg: " + items);

        print("Number of items: " + items.size());

        print("Index of Cup: " + items.indexOf("Cup"));
        print("Index of Zebra: " + items.indexOf("Zebra"));

        print("Item at index 3 is: " + items.get(2));

        print("Do we have a Box?: " + items.contains("Box"));
        print("Do we have an Apple?: " + items.contains("Apple"));

        items.clear();
        print("After clearing: " + items);
    }

    private static void print(String text) {
        System.out.println(text);
    }
}

Before adding any items:[]
After adding four items: [Apple, Box, Cup, Dart]
After removing Box: [Apple, Cup, Dart]
After adding Banana: [Apple, Banana, Cup, Dart]
After adding Egg: [Apple, Banana, Cup, Dart, Egg, Cup]
Number of items: 6
Index of Cup: 2
Index of Zebra: -1
Item at index 3 is: Cup
Do we have a Box?: false
Do we have an Apple?: true
After clearing: []

[Try the above code on Repl.it]

HashMap is an implementation of the Map interface. It allows you to store a collection of key-value pairs. The example below illustrates how to use a HashMap<String, Point> to maintain a list of coordinates and their identifiers e.g., the identifier x1 is used to identify the point 0,0 where x1 is the key and 0,0 is the value.

import java.awt.Point;
import java.util.HashMap;
import java.util.Map;

public class HashMapDemo {
    public static void main(String[] args) {
        HashMap<String, Point> points = new HashMap<>();

        // put the key-value pairs in the HashMap
        points.put("x1", new Point(0, 0));
        points.put("x2", new Point(0, 5));
        points.put("x3", new Point(5, 5));
        points.put("x4", new Point(5, 0));

        // retrieve a value for a key using the get method
        print("Coordinates of x1: " + pointAsString(points.get("x1")));

        // check if a key or a value exists
        print("Key x1 exists? " + points.containsKey("x1"));
        print("Key x1 exists? " + points.containsKey("y1"));
        print("Value (0,0) exists? " + points.containsValue(new Point(0, 0)));
        print("Value (1,2) exists? " + points.containsValue(new Point(1, 2)));

        // update the value of a key to a new value
        points.put("x1", new Point(-1,-1));

        // iterate over the entries
        for (Map.Entry<String, Point> entry : points.entrySet()) {
            print(entry.getKey() + " = " + pointAsString(entry.getValue()));
        }

        print("Number of keys: " + points.size());
        points.clear();
        print("Number of keys after clearing: " + points.size());

    }

    public static String pointAsString(Point p) {
        return "[" + p.x + "," + p.y + "]";
    }

    public static void print(String s) {
        System.out.println(s);
    }
}

Coordinates of x1: [0,0]
Key x1 exists? true
Key x1 exists? false
Value (0,0) exists? true
Value (1,2) exists? false
x1 = [-1,-1]
x2 = [0,5]
x3 = [5,5]
x4 = [5,0]
Number of keys: 4
Number of keys after clearing: 0

[Try the above code on Repl.it]

Classes form the basis of class diagrams.

Associations are the main connections among the classes in a class diagram.

The most basic class diagram is a bunch of classes with some solid lines among them to represent associations, such as this one.

An example class diagram showing associations between classes.

In addition, associations can show additional decorations such as association labels, association roles, multiplicity and navigability to add more information to a class diagram.

Here is the same class diagram shown earlier but with some additional information included:

Object diagrams can be used to complement class diagrams. For example, you can use object diagrams to model different object structures that can result from a design represented by a given class diagram.
